Additional Information
| Base Model | The OEM PC can be based on HP or Dell USFF PC – other models available upon request |
|---|---|
| TEMPEST Level | A |
| Casing | Mini PC (USFF) |
| Processor | Up to i5 13th Generation Intel® Core™ |
| Memory | 8GB DDR4-3200 (max 64GB DDR4-3200) |
| Chipset | Intel® Q670 |
| Graphics | Additional add-in graphics cards available upon request, Integrated Intel® UHD Graphics 710 with Intel® Celeron® G6900 |
| Sound | Integrated sound card and speaker |
| Storage | 500GB SATA 7200rpm Fixed hard disk drive |
| Optical Drive | None |
| Interface ports | 1x DisplayPort, 2x front, 2x rear USB 2.0 (DB9), 1x USB Keyboard & 1x USB mouse port (DB9) |
| Keyboard | 105-Key QWERTY International Windows keyboard |
| Pointing device | Optical 2-button mouse with scroll wheel |
| Security | PnP and BIOS setup/boot password/setup password, TPM 2.0 chip on motherboard |
| Network | 1Gbps or 100Mbps Fibre Ethernet interface LC/SC connectors |
| Power | TEMPEST Level A Filtered Power supply, 110-230VAC 50/60Hz auto, 1.8m shielded power cable with country specific mains plug |
| Operating system | Windows 10 Pro 64-bit |
| Dimensions (HxWxD) | 8 x 34 x 30cm, Weight: 4kg |
