Additional Information
| Base Model | The OEM PC can be based on HP or Dell Tower PC – other models available upon request |
|---|---|
| TEMPEST Level | A |
| Casing | Aluminium Midi Tower |
| Processor | Up to 13th Generation Intel® Core™ i9-13900K |
| Memory | 8GB, DDR5-4400 (max 128GB DDR5-3600) |
| Chipset | Intel® Q670 |
| Graphics | Additional add-in graphics cards available upon request, Integrated Intel® UHD Graphics 730 with13th Generation Intel® Core™ i5-13100 and i5-13400 processors |
| Sound | Integrated sound card and speaker |
| Storage | 500GB SATA 7200rpm Removable hard disk drive, (additional or higher capacity HDD, SDD or M.2 storage) |
| Optical Drive | DVD+/-RW super-multi Lightscribe optical drive |
| Interface ports | 1x DisplayPort, 2x front, 2x rear USB 2.0 (DB9), 1x USB Keyboard & 1x USB mouse port (DB9) |
| Keyboard | 105-Key QWERTY International Windows keyboard |
| Pointing device | Optical 2-button mouse with scroll wheel |
| Security | PnP and BIOS setup/boot password/setup password, TPM 2.0 chip on motherboard |
| Network | 1Gbps or 100Mbps Fibre Ethernet interface LC/SC connectors |
| Power | TEMPEST Level A Filtered Power supply, 110-230VAC 50/60Hz auto, 1.8m shielded power cable with country specific mains plug |
| Operating system | Windows 11 Pro 64-bit |
| Dimensions (HxWxD) | 46 x 20 x 59cm, Weight: 15kg |
