Additional Information
| Base Model | The OEM PC can be based on HP or Dell SFF PC – other models available upon request |
|---|---|
| TEMPEST Level | A |
| Casing | Aluminium Small Form Factor (SFF) |
| Processor | Up to 13th Generation Intel® Core™ i9 processor |
| Memory | Max. 128 GB DDR5-4800 SDRAM |
| Chipset | Intel® Q670 (vPro®) |
| Graphics | Integrated: Intel® UHD Graphics 730; Intel® UHD Graphics 770 |
| Sound | Integrated sound card and speaker |
| Storage | 1TB SATA Removable hard disk drive, (Higher capacity HDD, SDD or M.2 storage available) |
| Optical Drive | DVD+/-RW super-multi Lightscribe optical drive |
| Interface ports | 1x DisplayPort, 2x front, 2x rear USB 2.0 (DB9), 1x USB Keyboard & 1x USB mouse port (DB9) |
| Keyboard | 105-Key QWERTY International Windows keyboard |
| Pointing device | Optical 2-button mouse with scroll wheel |
| Security | PnP and BIOS setup/boot password/setup password, TPM 2.0 chip on motherboard |
| Network | 1Gbps or 100Mbps Fibre Ethernet interface LC/SC connectors |
| Power | TEMPEST Level A Filtered Power supply, 110-230VAC 50/60Hz auto, 1.8m shielded power cable with country specific mains plug |
| Operating system | Windows 11 Pro 64-bit |
| Dimensions (HxWxD) | 37 x 12 x 42.5cm, Weight: 7.5kg |
